Quenched and Tempered Alloy Steel
At least 25% greater WLL than traditional G80 products
Manufactured in accordance with EN 1677- 3 and ASME B30.26, ASME B30.10, PAS1061
Certified by DGUV GS-OA-15-05
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
Design Factor 4:1
Fatigue rated to 20,000 cycles at 1.5 times the WLL
Tempering temperature minimum 400°C
Magnaflux crack detection is performed 100% on each batch
| SKU | Capacity (t) | For Grade 100 Chain (mm) | Weight (kg) |
| 276-58-1 | 1.4 | 6 | 0.4 |
| 276-58-2 | 2.5 | 7, 8 | 0.9 |
| 276-58-3 | 4 | 10 | 1.4 |
| 276-58-4 | 6.7 | 13 | 3 |
| 276-58-5 | 10 | 16 | 5 |
| 276-58-6 | 16 | 20 | 11 |
| 276-58-7 | 19 | 22 | 13.5 |
Quenched and Tempered Alloy Steel
At least 25% greater WLL than traditional G80 products
Manufactured in accordance with EN 1677- 3 and ASME B30.26, ASME B30.10, PAS1061
Certified by DGUV GS-OA-15-05
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
Design Factor 4:1
Fatigue rated to 20,000 cycles at 1.5 times the WLL
Tempering temperature minimum 400°C
Magnaflux crack detection is performed 100% on each batch
| SKU | Capacity (t) | For Grade 100 Chain (mm) | Weight (kg) |
| 276-58-1 | 1.4 | 6 | 0.4 |
| 276-58-2 | 2.5 | 7, 8 | 0.9 |
| 276-58-3 | 4 | 10 | 1.4 |
| 276-58-4 | 6.7 | 13 | 3 |
| 276-58-5 | 10 | 16 | 5 |
| 276-58-6 | 16 | 20 | 11 |
| 276-58-7 | 19 | 22 | 13.5 |
